Model No. |
LD-240 |
Lifting Capacity |
4000kg |
Lifting Height |
1800/1845mm(option 1900/1945mm) |
Min. Height |
Min.95mm- Max.135mm |
Total Height |
2800mm |
Total Width |
3470mm |
Column Inside |
2830mm |
Lifting Time |
About 50sec. |
Lowering Time |
About 35sec. |
Net Weight |
700kg |
Operation Method |
Electrical Release |
Packing Size |
2950(H)x1000(W)x500(H)mm |
Power & Motor |
1Phase(2.5HP, 4P, 220V, 50/60HZ) |
Power & Motor |
3Phase(2HP, 4P, 220V/380V, 50/60Hz) |
|
